STTR Tensioner



Pneumatic tensioner easy to use and set. Strong and reliable to use in industrial heavy applications. Available standard with push button version is also supplying, on domand, in choke collar version. The particolar conformation is able to use straps from 19mm(3/4") up to 32mm(1-1/4") without any adjustments.



Products are Made by SIAT



Specification     |     Features     |     Applications



Home Our Products Automatic Packing Tools STTR Tensioner

STTR Tensioner

Model STTR Tensioner
Package type Flat,round and irregular surfaces
Strap quality Bright – blue - high tensile Rmax=1100 N/mm2
Strap Width From 19mm upto 32mm (3/4"- 1-1/4")
Strap thickness From 0,6 upto 1,1mm (0.024"- 0.043")
Max. tension Around 9000N
Air pressure and comsumption from 5 upto 6,5 bar MAX/12Lt/sec
Max. tensioning speed Around 6 mt/min
Weight Around 4,1 Kg (button) - 4,3 Kg (choke collar)
Order code push button version 104.990.110
Order code choke collar version 104.990.120

Features

  • Easy to Use
  • Ergonomic and Modern Design
  • Light and Compact
  • Equipped by Bosch Pneumatic Motors



For More Details Click Here


Applications

Automatic Packing Tools
